Short Description:

Market competition is getting fiercer. Many major filter manufacturers are now sourcing high-quality, lower-cost filter media from China to replace Alstrom, HV and other conventional filter papers. And we’ve got the solution!

Send email to us

Product Detail

Product Tags

Super Synthetic Fibre Filter Paper – Outer HD (50% Synthetic / 50% Cellulose)

♦ 25% high efficiency.
♦ Fluffy substrate enabling fewer pleats to cut overall costs.
♦ Features excellent water resistance and a service life exceeding 50,000 km.
♦ It reduces fuel consumption by 2–2.5 liters per 100 km.

Super Synthetic Fibre Filter Paper – Safety Inner HD (80% Synthetic / 20% Cellulose)

♦ More than 80% synthetic
♦ Good water Resistance
♦ Easy pleating, good shape
♦ 30% consumption of paper saved compare with 100% cellulose paper.
♦ Lower weight 90-100g, Fluffy thickness 0.65+/-0.05

Specification

Item	Weight (g/m2)	Thickness (mm)	Corrugation/Flat (mm)	Burst Strength (Kpa)	Air Permeability (L/m2.s)	Stiffness (m.Nm)	Remark
Inner Air Filter(Safty, Secondary Filter)
3	90-95	0.45±0.05	0	≥150	1000±100	≥1.0	80% synthetic
4	90-95	0.60±0.10	0	≥150	1400±100	≥1.5	80% synthetic
5	95±5	0.60±0.10	0	≥150	1600-1800	≥1.0	80% synthetic

Our inner filter paper (80% synthetic) how to save your pocket!

Paper Weight	Paper Thickness	Pleating Numbers	Pleating Height (mm)	Width(mm)	Paper cost(kgs)
100% cellulose paper 115g	0.65+/-0.05	230	32	420	0.710976
80% synthetic,20%cellulose 95+/-5g	0.65+/-0.05	230	32	420	0.587328
				Save paper:	0.123648
Result: Each filter equipped with calibrated detentions reduces filter paper consumption by 0.12 kg！
