Oil Filter Paper

Short Description:

As the core filtration medium of an oil filter, oil filter paper achieves high-efficiency removal of metal wear debris, carbon deposits and particulate contaminants through its precision fiber layer. Engineered for an optimal balance of filtration efficiency, dirt-holding capacity and flow resistance, it is a key component in maintaining lubricating system cleanliness, reducing mechanical wear, and extending oil change intervals and engine service life.

Send email to us

Product Detail

Product Tags

Features

♦ Long Life Working
♦ Water Resistance

Specification

Item	Weight(g/m2)		Thickness (μm)	Corrugation/Flat (μm)	Burst Strength(Kpa)		Air Permeability (L/m2.s)	Stiffness(m.Nm)		Phenolic/Acrylic
Spiral Tube Oil Filter Paper
	SD	SDC			SD	SDC		SD	SDC
1	120	115	720	300	130	150	550	4	5	Phenolic
2	125	121	600	0	120	170	850	5	6	Phenolic
3	145	139	780	300	100	200	440	4	6	Phenolic
4	160	155	900	300	200	250	380	8	10	Phenolic
5	187	181	950	300	150	200	460	10	12	Phenolic
6	189	183	900	0	200	250	680	13	15	Phenolic

Item	Weight(g/m2)		Thickness (μm)	Corrugation/Flat (μm)	Burst Strength(Kpa)		Air Permeability (L/m2.s)	Stiffness(m.Nm)		Phenolic/Acrylic
Eco Oil Filter Paper
	SD	SDC			SD	SDC		SD	SDC
1	190	184	780	0	200	300	500	12	15	Phenolic
2	208	200	1000	300	250	350	460	13	15	Phenolic
3	212	202	1100	250	180	250	650	13	15	Phenolic
4	208	200	1000	300	250	350	550	13	15	Phenolic
5	208	200	1000	300	250	>200	460-500	13	15	Phenolic
